Logic Gates

IC Based Logic Gates Apparatus has been designed to verify the truth table for following Gates:
1. AND Gate (IC 7408)
2. OR Gate (IC 7432)
3. NOT Gate (IC 7404)
4. EX-OR Gate (IC 7486)
5. NAND Gate
6. NOR Gate
7. EX- NOR Gate

The Instrument comprises of the following Built in Parts:
1. Fixed output DC regulated power supply of 5V DC.
2. Three logic inputs “0” & “1” inputs selectable through SPDT switches are provided on the front panel.
3. One Red LED output indicator is provided on the front panel to observe the output status.
4. The symbols of each gate are printed on the front panel and connections for the input & output are brought in the sockets. All IC’s are placed inside the cabinet.
